IMX179

CMOS sensor model：IMX179

CMOS sensor Size：1/3.2 Inch

Output full resolution：3264*2448

Pixel size：1.4um*1.4um

TV Distortion：<5%

IR Specification：Glass without coating

Product Details

CMOS sensor model	IMX179
CMOS sensor Size	1/3.2 Inch
Output full resolution	3264*2448
Pixel size	1.4um*1.4um
TV Distortion	<5%
IR Specification	Glass without coating
Field of View	Diagnal:68 degree ,Horizontal:57 degree,Vertical:44 degree
Output port type	USB2.0 （BF 180 degree or 1.5mmX4PIN terminal）
Effective full resolution&frame	MJPG 32642448 15fps; YUY2 32642448 1.5fps
Normal resolution&frame	MJPG 25921944/20fps;20481536/20fps; 19201080/30fps;1280720/30fps；800600/30fps；640480/30fps; YUY2 25921944/2.5fps;20481536/3.75fps;19201080/5fps;1280720/10fps;800600/20fps;640480/30fps;
Hoster computer software customized	Can customized client application
Power consumption（Full resolution）	P=0.75W 5V*150mA
Operation temerature	0℃~60℃
Storage temerature	-40℃~85℃
supporting platform	Linux,windows,Android
Application	Education,Bank,others
Driver	No need
ESD level	USB2.0 Contact discharge 4KV,Not-contact discharge15KV
Dimension，2D drawing	Structure 1: 45*45mm;Structure 2→38 boards overlay,detail dimension as 2D
ROHS	Complicate
